PSC RF 4 Pack RF and Power Distributor

The new PSC RF 4 Pac is very similar to our RF 6 Pack. It is a smaller, more compact version and also incorporates a battery distribution system (BDS). By combining these two products, the end user saves weight, size and cabling in their bag setups. This product supports both analog and AES Digital audio outputs. It will support up to 8 channels of Digital Audio when used with the new Wisycom receiver in AES mode. This product provides RF and power distribution to two slot receivers. It also has two RF output connectors for easy daisy chaining of two units, or to feed RF to another device. The power distribution section accepts two external batteries. These can be NP-1 or the newer “Smart” batteries. A convenient multi-color LED battery meter is provided. Battery metering is selectable for various battery types (voltages). Audio outputs are available as mini XLR and also on a DB-15 Multipin connection.

• Supports Two Slot Receivers.
• Built in RF Distribution and Filtering.
• Provides Remote Antenna Powering.
• Build in Battery Distribution System.
• Takes two external batteries.
• Provides multi-color LED battery metering.
• Possible Aaton Hydra Interface Option In the Future if Customer Demand Warrants it.
• Made in the U.S.A.

Frequency band: 470-700 Mhz
Dimensions: 9.25” x 5.75” x 1.6” (23.5cm x 14cm x 4cm)
Weight: 1.6 Lbs. (0.725 kg)
Power: External DC, 12 to 18Vdc @ 170mA

NOTA: Per la variante con interfaccia Aaton, chiedeteci la disponibilità (al 30/9/21 non è ancora pronta) e il prezzo.
